MiR Charge 24V

MiR Charge 24V is a fully automatic charging station that lets MiR robots autonomously reload their batteries as needed. This small, non-intrusive charging station uses standard power and can be easily integrated into almost any environment.

DESCRIPTION
SPECIFICATIONS

Edit Content

Keep robots running around the clock
Your MiR100 or MiR200 robot will never run out of power in the middle of a job. MiR Charge 24V is a fully automatic charging station that offers flexible deployment options to meet your needs.

Collaborates with MiR Fleet
The robot autonomously returns to the charging station and connects when its battery falls under established limits. It can also be programmed to regularly recharge between deliveries, such as when it returns to a stockroom or depot, which can allow the robot to run nearly continuously. MiR Charge 24V fully charges a MiR robot in about two hours. When multiple robots are deployed using MiR Fleet, the system evaluates battery levels and job loads, optimizing utilization and recharging to keep the fleet on the job around the clock.

Discreet and easy to install
MiR Charge 24V is easy and unobtrusive to install in your facility. It uses standard power outlets and its low profile and small footprint give you additional flexibility in how you power and deploy your mobile robot.

Edit Content

General Information

Designated use	Automatic charger for MiR100 and MiR200 robots. The robot moves and connects to the charging station
Color	RAL 7035 / Light gray
Disclaimer	Specifications may vary based on local conditions and application setup

Dimensions

Width	620 mm \| 24.4 in
Height	350 mm \| 13.8 in
Depth	120 mm \| 4.7 in
Weight	10.5 kg \| 22 lbs
Minimum distance between chargers	100 mm \| 3.9 in if the robot can approach the charger in an angle of 80-100° to the wall

Mounting

Wall mounting

To be mounted flush with floor 45 mm | 1.8 in from floor to bottom edge

Environment

Humidity	10–95% non-condensing
Ambient temperature range, operation	5–40°C \| 41–104°F
Maximum altitude	2 000 m \| 6 562 ft

Power

Output	24 V, maximum 25 A
Input	100–240 V AC, 50–60 Hz
Consumption	Nominal 7.3 A at 100 V AC, nominal 2.9 Amp at 240 V AC

Compliance

Electrical standards

EN60335-2-29
