MiR EU Pallet Lift 600

Increase efficiency by automating your internal transportation of pallets with the MiR600 and the MiR EU Pallet Lift 600 top module that autonomously picks up and delivers pallets throughout your facility with high speed.

DESCRIPTION
SPECIFICATIONS

Edit Content

Centralized control of robots
MiR Fleet offers centralized control of robots from a single station, throughout all your facility, thanks to an intuitive web-based interface.

Easy programming of the robots for different operations
It is easy to program and control a robot fleet, including robots with different top modules, Hooks or other accessories. Once the programming phase is over, the system manages the priorities and selects the most suitable robot to the operation that needs to be carried out, based on position and availability.

Edit Content

General Information

Designated use	For autonomous pickup and unload of EUR-pallets
Color	RAL 9005 / Signal Black
Disclaimer	Specifications may vary based on local conditions and application setup

Dimensions

Length	1 200 mm \| 47.2 in
Height	87 mm \| 3.4 in
Total height in lifted position	150 mm \| 5.9 in
Lifting height	60 mm \| 2.4 in

Payload

Maximum lift payload

500 kg | 1 100 lbs

Performance

Number of lift cycles (with maximum payload)	Minimum 90 000
Lifting speed	Up: 4.0 s Down: 3.2 s

Pallets

EUR-pallets dimensions	1 200 x 800 mm \| 47.2 x 31.5 in
Pallet production specifications	EN 13698-1
